Model No	Ball circuit	weight(gf)	Inscribed clecle diameter		Outer diameter		Length		B		W	D1	Eccentricity (max) µm	Radial clearance tolerance	Basicload rating
			dr	Tolerance	D	Tolerance	L	Tolerance		Tolerance					CN	CoN
LM6LUU	4	16	6	0 -0.010	12	0 -0.013	35	0 -0.3	27	0 -0.3	1.1	11.5	15	15	324	529
LM8LUU	4	31	8		15		45		35		1.1	14.3	15	15	413	784
LM10LUU	4	62	10		19	0 -0.016	55		44		1.3	18	15	15	588	1100
LM12LUU	4	80	12		21		57		46		1.3	20	15	15	657	1200
LM13LUU	4	90	13		23		61		46		1.3	22	15	15	814	1570
LM16LUU	5	145	16		28		70		53		1.6	27	15	15	1230	2350
LM20LUU	5	180	20	0 -0.012	32	0 -0.019	80		61		1.6	30.5	20	20	1400	2750
LM25LUU	5	440	25		40		112	0 -0.4	82	0 -0.4	1.85	38	20	20	1560	3140
LM30LUU	6	580	30		45		123		89		1.85	43	20	20	2490	5490
LM35LUU	6	795	35	0 -0.012	52	0 -0.022	135		99		2.1	49	25	25	2650	6470
LM40LUU	6	1170	40		60		154		121		2.1	57	25	25	3430	8040
LM50LUU	6	2100	50		80		192		148		2.6	76.5	25	25	6080	15900
LM60LUU	6	3500	60	0 -0.020	90	0 -0.025	211		170		3.15	86.5	25	25	7650	20000
